Melting facilities

Arc Melter

Technical Data:

  • Arc-Melting Chamber (Edmund Bühler)
  • Power max: 18.5 kW
  • Current max: 400 A
  • Volume: 18 l
  • Vacuum: 10-6 mbar (0.000001 mbar)
  • Purging gases: He, Ar, N2
  • Pressure max: 1.2 bar

Application:

Melting of high melting point materials (4000 K) under defined and controlled conditions, under inert gases (He, Ar, N2)

AMelter1_pic_01
AMelter2_pic_01

RF Generator

Technical Data:

  • Induction heater ISM HF20 (Cheltenham)
  • 3 work heads
  • Power max: 20 kW
  • Frequency: 50 – 150 kHz
  • Voltage max: 1000 V

Application:

Induction melting and hardening with tailored RF coils in vacuum inert gases and atmosphere

cheltenham_01

Melt Spinner

Schmelzspinner_01

Technical Data:

Wheel Speed: 5 - 55 m/s
Vacuum: 10-6 mbar
Max. controlled Temperature: 1600°C
Gases: He, Ar, N2

Application:

Quenching rates up to 10+6 °C/s permit freezing of liquid or glassy structures to study kinetic phenomena of nucleation and growth.

Vacuum Caster

Vakuum_Kipp_01

Technical Data:

  • Melt volume in tilt crucible: 1 l
  • Max. Temperature: 2500 K
  • Vacuum: 10-5 mbar
  • Gases: He, Ar, N2

Application:

Controlled melting under vaccum or in the atmosphere to produce gravity feed casting or test bars for alloy development

Multi-caster

MCaster_pic_01

Technical Data:

Melt volume dependent of melt unit
Max. Temperature: 2500 K
Vacuum: 10-4 mbar
Gases: He, Ar, N2

Application:

Controlled melting under vaccum or in controlled atmosphere to produce gravity feed casting or test bars for alloy development. Various melt units can be applied in the multi-caster:

  • Gravity Stop-pour Casting
  • RF Heating
  • Differential Pressure Casting

Electric resistance furnance

ausstattung-schmelzeinrichtungen-schmelzofen-neu_NEU_01

Technical Data:

Electric resistance furnace T20 (Nabertherm)

  • Temperature max: 950 °C
  • Volume: 10 l
  • Power: 15 kW

Technical Data:

Electric resistance furnace K40/12 (Nabertherm)

  • Temperature max: 1100 °C
  • Volume: 40 l
  • Power: 26 kW

Application:

Crucible frunaces to melt Al and Mg alloys

DSC_0444_01
